1762-L40BXB Allen Bradley ControlLogix 16 Point D/O Module

Brand Name : Allen Bradley

Model Number : 1762-L40BXB

Place of Origin : USA

MOQ : 1

Price : 1-99$

Payment Terms : T/T

Supply Ability : 999

Delivery Time : in stock / 1-3 work days

Packaging Details : Brand New Original

Product Type : Programmable Controller

Power Supply : 24V dc ( -15%, +10%) Class 2 SELV

No. of Inputs : Twenty-Four (24)

No. of Outputs : Sixteen(16)

Input Power : 24 Volts DC

Inputs : (20) 24 Volt DC and (4) Fast 24 Volt DC

Applicantions : Industrial Automation

Brand : Allen Bradley

Rated voltage : 220V

Protection level : IP65

Product certification : CCC, UL

Contact Now

Description

The Allen-Bradley 1762-L40BXB is a MicroLogix 1200 programmable controller. The module has 24 inputs and 16 outputs and weighs 2.4 pounds. The power supply is 100 to 240 VAC, 47 to 63 Hz. The module dissipates 21 W. The power supply dissipates 80 VA. The power supply output is 600 mA at 5 V DC and 500 mA at 24 V DC. The input circuit type of the 1762-L40BXB is a 120 V AC circuit and the output circuit is a relay/field effect transistor (FET) type. The 1762-L40BXB has two (2) input groups. The first group is for inputs 0 to 3 and the second group is for inputs 4 and above. For inputs 0 to 3, the on voltage is 14 to 24 V DC, the off voltage range is 0 to 5 V DC, and the operating frequency is 0 to 20 kHz. The nominal impedance is 3.3 KΩ. For inputs 4 and above, the on voltage range is 10 to 24 V DC, the operating frequency is 0 to 1 kHz, and the nominal impedance is 2.7 KΩ. Inputs 0 to 3 and inputs 4 and above have the same off leakage current of 1.5 mA. The 1762-L40BXB has a current of 8 A per group. Do not exceed the common specification of each group current to avoid damaging the module.
